7/8 Panel Mount

Description

• Connector series: 7/8″Mini-change
• Gender: Male
• Locking type: Fix screw
• Mounting type: Front fastened

• General information



  Ambient temperature:	-25℃ ~ +90℃
  Connector insert:	TPU
  Connector contacts:	Brass with gold plated
  Coupling nut/screw:	Brass with nickel plated
  Seal/O-ring:	Epoxy resin/FKM
  Insulation resistance:	≥100MΩ
  Contact resistance:	≤5mΩ
  Shielding：	Unavailable
  IP rating:	IP67 in locked condition

  Electrical data & Mechanical data



  Contacts	Rated current	Voltage		Wire gauge/size		Contacts termination	Wire insulation	Cable ending & length
  		A/C	D/C	AWG	mm²
  03 pins	15A	300V	300V	14	1.93	Crimp	PVC	Custom version available
  04 pins	15A	300V	300V	14	1.93	Crimp	PVC
  05 pins	8A	300V	300V	20	0.5	Crimp	PVC
