7/8 Right Angle Male

Description

• Connector series: 7/8″Mini-change
• Gender: Male
• Locking type: Fix screw
• Mounting type: Right angled


  General information

  Ambient temperature:	-20℃ ~ +80℃
  Connector insert:	TPU
  Connector contacts:	Brass with gold plated
  Connector over-molding:	TPU
  Coupling nut/screw:	Aluminium anodized black
  Insulation resistance:	≥100MΩ
  Contact resistance:	≤5mΩ
  Shielding：	Unavailable
  IP rating:	IP67 in locked condition

  Electrical data & Mechanical data

  Contacts	Rated current	Voltage		Wire gauge/size		Cable jacket	Wire insulation
  		A/C	D/C	AWG	mm²
  03 pins	13A	300V	300V	18	1.0	PUR/PVC	PVC
  04 pins	13A	300V	300V	18	1.0	PUR/PVC	PVC
  05 pins	8A	300V	300V	20	0.5	PUR/PVC	PVC
